| Model | 7TS |
| Production dimension (L/W/H *inch) | 39/10.6/18.5 |
| Net weight (LBS) | 99 |
| Packing size (inch) | 42.5/12.8/20.5 |
| Total weight of packing (LBS) | 110 |
| Horizontal/Vertical | Horizontal |
| Splitting method (optional) | 2 ways/4 ways |
| Cycle | 15S |
| Working voltage/Hz | 115V/60Hz |
| Motor power | 3HP |
| Protection level | IP54 |
| Splitting stroke Length (inch) | 22 |
| Splitting diameter φ (inch) | 0.2-15.8 |
| Operating method | Hands |
| Max. tonnage | 7.5T |
| Hydraulic oil No. | 46# |
| Tires | 6×1.5 |
| Hydraulic oil | 0.8GAL |
| Inner diameter of cylinder (inch) | 2.2 |
| Piston diameter (inch) | 1.2 |
